• TR-Type Fender TR fender consists of two independent legs of solid rubber bolted to a wide steel-framed rubbing board protected with square pads of high quality plastic material. |
 |
 |
 |
| • Dimension (Unit:mm) |
| Dimension | MD | A | B | C | E | F | T | W | L |
| Height | |||||||||
| 600H | M48 (2) | 1435 | 450 | 375 | 592.5 | 180 | 50 | 965 |
1000 ~ 3000 |
| 800H | M64 (2 1/2) | 1850 | 585 | 480 | 765 | 240 | 60 | 800 | |
| 1000H | M64 (2 1/2) | 2180 | 685 | 610 | 890 | 300 | 65 | 1000 | |
| 1150H | M64 (2 1/2) | 2500 | 800 | 650 | 1005 | 345 | 65 | 1150 | |
| 1300H | M76 (3) | 2740 | 880 | 750 | 1115 | 395 | 65 | 1300 | |
| 1450H | M76 (3) | 3100 | 1000 | 800 | 1300 | 675 | 100 | 1450 | |
| 1600H | M76 (3) | 3300 | 1100 | 800 | 1400 | 750 | 100 | 1600 | |
| 1800H | M76 (3) | 3670 | 1200 | 970 | 1500 | 830 | 110 | 1800 | |
| 2000H | M76 (3) | 4050 | 1300 | 1150 | 1600 | 880 | 120 | 2000 | |
| 2250H | M76 (3) | 4400 | 1400 | 1300 | 1700 | 945 | 130 | 2250 | |
| 2500H | M76 (3) | 4860 | 1500 | 1560 | 1800 | 1000 | 140 | 2500 |
 |
 |
| • Compression Test |
|
• Performance Curve
|
• Performance of Intermediate Deflection
|
| • 3D Model |
 |
 |
| • Performance Table, Pianc Factor, Angular Berthing and Angular Performance Factor View asiafender catalogue to know more detail infomation |
