Ports/Harbour C-Gard platform anodes are available in a variety of sizes and insert dimensions. The table below lists the standard anode sizes available in straight through insert designs. Select the anode dimensions required and the insert type. The insert can be designed to meet your specific requierements for fixing methods. We have a number of frame and sled design systems that have been developed to reduce diver time and underwater welding, which means that you are able to deliver projects quicker and at lower cost. If the anode required is not listed Impalloy can create a suitable anode either from our stock of existing moulds, or we can fabricate moulds to suit in our extensive fabrication facilities. C-Gard Platform Anodes |
| Anode Type | Length mm | Width mm | Depth mm | Insert Diameter mm | Alloy net weight Kg | Alloy Nett Weight per Metre Kg | |
| Round bar | Tubular Nominal Bore | ||||||
| 350XP-S16- | 1301 | 101 | 101 | 20 | 35 | 26.9 | |
| 800XP | 2365 | 114 | 114 | 25 | 80 | 33.8 | |
| 500XP | 1300 | 120 | 120 | 20 | 50 | 38.5 | |
| 680XP | 1515 | 133 | 127 | 20 | 68 | 44.9 | |
| 1190XP | 1526 | 184 | 159 | 25 | 119 | 78.0 | |
| 1240XP | 1800 | 160 | 162 | 25 | 124 | 68.9 | |
| 1640XP | 2454 | 160 | 162 | 40 | 164 | 66.8 | |
| 1480XP | 2373 | 160 | 162 | 50 | 148 | 62.4 | |
| C-Sentry Flush Mounted Anodes |
| Anode Type | Length mm | Width mm | Depth mm | Insert Diameter mm | Alloy net weight Kg | Alloy Nett Weight per Metre Kg | |
| Flat Bar | Overall length | ||||||
| 202XH | 838 | 133 | 78 | 50x6 | 1038 | 20.2 | 22.7 |
| 320XH | 1219 | 152 | 64 | 50x6 | 1435 | 32 | 35.4 |
| 352XH | 1159 | 175 | 65 | 50x6 | 1435 | 35.2 | 38.5 |
| 681XH | 1515 | 133 | 127 | 40x8 | 1715 | 68.1 | 72.4 |
 |
 |
 |
